| Manufacturer: | Kingston |
|---|---|
| Product Name: | Kingston DDR4-3200 8GB |
| Model Number: | KVR32N22S6/8 |
| SKU: | 0156 |
| EAN: | 0740617310870 |
| Warranty: | Lifetime limited warranty direct with manufacturer |
This document describes ValueRAM's KVR32N22S6/8 is a 1G x 64-bit (8GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 1Rx16, memory module, based on four 1G x 16-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers.
| Memory Type: | DDR4 |
|---|---|
| Capacity: | 8 Gb |
| Clock Speed: | 3200 MHz |
| CAS Latency: | 22 |
| Voltage: | 1.2 V |
| Pins: | 288 |
| Rank: | Single |
| Description: | This document describes ValueRAM's KVR32N22S6/8 is a 1G x 64-bit (8GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 1Rx16, memory module, based on four 1G x 16-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers. |
| Package Type: | Retail |
|---|
