| Manufacturer: | Toshiba |
|---|---|
| Product Name: | Toshiba MG11 Series 20TB Enterprise SATA |
| Model Number: | MG11ACA20TE |
| SKU: | 5613 |
| EAN: | 4260557513606 |
| Warranty: | 5-year limited warranty direct with manufacturer |
Built on 50 years of Toshiba’s HDD innovation, the MG11 Series delivers new levels of capacity, performance, and quality. Packing up to 24TB into a standard 3.5-inch conventional magnetic recording (CMR) HDD, the MG11 Series enables cloud-scale infrastructure to build higher storage densities at lower TCO. The MG11 Series features up to a 10-disk helium-sealed 3.5-inch design, which leverages Toshiba’s innovative Flux Control Microwave Assisted Magnetic Recording (FC-MAMR™) technology to achieve 2.4TB per disk. Built to meet growing data storage demands, the MG11 Series has a high workload rating of 550TB with 7200 rpm, and is available in 6Gbps SATA and 12Gbps SAS interfaces. Engineered for 24/7 quality and enterprise reliability, the MG11 Series has an MTTF of 2.5 million hours. SED and SIE options are available to secure data and deliver peace of mind. In addition to 24TB, the MG11 is available in 22TB, 20TB, 18TB, 16TB, and 14TB in both SAS and SATA interfaces with SIE and SED options.
| Product Serie: | MG11 |
|---|---|
| Form Factor: | 3.5" |
| Enclosure Type: | Internal |
| Capacity: | 20 TB |
| Storage Interface: | SATA-3 |
| Data Transfer Rate: | 6 Gbit/s |
| Rotational Speed: | 7200 RPM |
| MTBF: | 2500000 h |
| Operating Voltage: | 7200 RPM |
| Temperature Operating: | 5 - 55 °C |
| Temperature Non-operating: | -40 - 70 °C |
| Shock Operating: | 50 G |
| Shock Non-operating: | 200 G |
| Product Width: | 101.8 mm |
| Product Length: | 147 mm |
| Product Height: | 26.1 mm |
| Product Net Weight: | 730 g |
| Description: | Built on 50 years of Toshiba’s HDD innovation, the MG11 Series delivers new levels of capacity, performance, and quality. Packing up to 24TB into a standard 3.5-inch conventional magnetic recording (CMR) HDD, the MG11 Series enables cloud-scale infrastructure to build higher storage densities at lower TCO. The MG11 Series features up to a 10-disk helium-sealed 3.5-inch design, which leverages Toshiba’s innovative Flux Control Microwave Assisted Magnetic Recording (FC-MAMR™) technology to achieve 2.4TB per disk. Built to meet growing data storage demands, the MG11 Series has a high workload rating of 550TB with 7200 rpm, and is available in 6Gbps SATA and 12Gbps SAS interfaces. Engineered for 24/7 quality and enterprise reliability, the MG11 Series has an MTTF of 2.5 million hours. SED and SIE options are available to secure data and deliver peace of mind. In addition to 24TB, the MG11 is available in 22TB, 20TB, 18TB, 16TB, and 14TB in both SAS and SATA interfaces with SIE and SED options. |
| Package Type: | OEM |
|---|
